Biodiesel oxidation - a big problem...

  Unlike mineral diesel, biodiesel is perishable and starts to oxidise as soon as it has been produced. It reacts with atmospheric oxygen to produce volatile compounds, corrosive carboxylic acids and polymerized / cross-linked biodiesel gums that can damage diesel engine components. Already certain fuel pump manufacturers have withdrawn warranties for B100 because of such gums and residues which are not due to biodiesel itself, rather the biproducts of biodiesel oxidation.

  Baynox® and Baynox Plus prevent the premature oxidation of unsaturated biodiesel esters and hence the formation of these problematic biproducts - keeping biodiesel fresh and extending it's shelf life.

Baynox ® Solution


Baynox® Solution Biodiesel Stabiliser (Baynox®) is suitable for making biodiesel storage-stable






  • Recommended for biodiesel produced from used cooking oils or rapeseed oil

  • Liquid form makes dosing and mixing simple


Can also be supplied in pure crystalline form


  • Available in quantities of 1 litre bottle, 25 litre drum, 200 litre barrel, 1,000 litre IBC, Isotank or road tanker delivery


Baynox® Solution Biodiesel Stabiliser is a mixture of 20% high purity Baynox dissolved in specially manufactured high-purity RME biodiesel which meets both E DIN 51606 and EN 14214.



Baynox does not have a corrosive action on metals and combusts without residue. It is not a hazardous material and does not require labeling in line with the Regulations on Hazardous Substances. It is not subject to the Regulations on Flammable Liquids (VbF).




Required treat rate is dependent upon the natural stability of the biodiesel used. The customer must determine the required dosage and check compatability with the biodiesel they have produced.



Usual addition rates are 0.1% to 0.5% by volume



(i.e. 1–5 litres made up to 1,000 litres with biodiesel)



Baynox® Solution is available to buy online






Product Information

          Baynox® Solution Biodiesel Stabiliser
Form

Liquid
Composition

1 litre contains minimum 200 g 2,6-Di-tert.-butyl-4-methylphenol dissolved in Biodiesel (min. 225 g/kg)


CAS-No.: 000128-37-0 (2,6-Di-tert.-butyl-4-methylphenol)


CAS-No.: 67762-40-7 (biodiesel)

Description

Clear, slightly yellow liquid with a characteristic odour of Biodiesel
Miscibility

Very good miscibility with biodiesel and organic solvents*


Not miscible with water*

Density at 20°C

Approx. 0.89 g/l*
Viscosity at 20°C

9.9 mm2/s*
Residue after ignition

Max. 20 ppm*
(active ingredient)

  * Provided as general information only. They are approximate values and are not considered part of the product specification

Baynox ® Plus Solution



Baynox® Plus Solution Biodiesel Stabiliser (Baynox® Plus ) is suitable for making biodiesel storage-stable


  • Baynox® Plus is effective for all types of biodiesel. It is particularly suited to more highly persihable types of biodiesel such as biodiesel produced from Soy, Sunflower or Jatropha oils

  • Liquid form - simple dosing and mixing -


Can also be supplied in pure crystalline form


Baynox® Plus Solution Biodiesel Stabiliser is a mixture of 20% high purity Baynox Plus dissolved in specially manufactured high-purity RME biodiesel which meets both E DIN 51606 and EN 14214


Baynox® Plus does not have a corrosive action on metals and combusts without residue. It is not a hazardous material and does not require labeling in line with the Regulations on Hazardous Substances. It is not subject to the Regulations on Flammable Liquids (VbF).



Required treat rate is dependent upon the natural stability of the biodiesel used. The customer must determine the required dosage and check compatability with the biodiesel they have produced.



Usual addition rates are 0.05% to 0.5% by volume (i.e. 0.5 – 5 litres made up to 1,000 litres with biodiesel)


Baynox® Plus Solution is available to buy online


Product Information

          Baynox® Plus Solution Biodiesel Stabiliser
Form
 Liquid
Composition
 1Kg contains minimum 200g 2,2'-Methylenebis(4-methyl-6-tert-butylphenol)
CAS No.: 119-47-1 - 2,2'-Methylenebis(4-methyl-6-tert-butylphenol)
CAS-No.: 67762-40-7 - biodiesel
Description
 Clear, slightly yellow to reddish liquid with a specific odour of biodiesel
Miscibility
 Micsible with all proportions of biodiesel
Not miscibile with water
Density at 20°C
0.89 kg/l
Ash
 < 200ppm

Disclaimer:
 The information provided above is given in good faith but without warranty, and this also applies where proprietary rights of third parties are involved. Any advice provided does not release you from the obligation to check its validity and to test the products as to their suitability for the intended processes and uses. The application, use and processing of this product and the products manufactured by you are beyond our control and, therefore, entirely your own responsibility.
